Welcome to GINsim

GINsim (Gene Interaction Network simulation) is a graphical application to ease the design and the dynamical analysis of Boolean and multilevel logical models of cellular regulatory networks.

GINsim relies on a graph-based representation of regulatory networks, called logical regulatory graph, as well as on a graph-based representation of the dynamics, called state transition graph.

Model definition, alteration and analysis

The GINsim graphical interface facilitates the definition of a logical regulatory graph (LRG) with the insertion and deletion of nodes, as well as of various kinds of directed arcs (activations, inhibitions, dual or unknown arcs). The user can further associate textual and hyperlink annotations to keep track of supporting data.

The logical rules defining the responses of a target node to the levels of their regulators can be encoded as classical Boolean expressions (using the AND, OR and Not operators), or in terms of combinations of interactions enabling the activation of the target node to a specified level (equivalent to Snoussi & Thomas’ logical parameters). Internally, these logical rules are encoded as multilevel decision diagrams, which are used for the computation of various dynamical properties.

A GINsim model can be associated with a series of perturbations (e.g. loss-of-function or ectopic activity of a node, or any combination thereof), as well as with a set of reference states (e.g. initial states), which can all be defined through graphical panels.

GINsim further includes:

• the verification of the consistency between the model graphical representation (arc occurrences and signs) with the logical rules associated with its nodes;
• the efficient computation of the stable states of a model;
• the identification of all regulatory circuits, evaluation of their signs based on the logical rules associated with their nodes, and assessment of their functionality sub-spaces;
• the colouring of the regulatory graph on stable states (displaying active nodes and interactions) or on user defined states;
• a multiple graph functionalities, also applicable to state transition graphs, and listed below;
• the possibility to reduce a model, by removing specific components;
• the conversion of a multivalued model into a Boolean one;
• the reversion of a model resulting in a model that produces a reverse (asynchronous) dynamics;
• the functionalities to import models encoded in a variety of formats, primarily sbml-qual, ensuring interoperability with other logical modelling tools (truth tables, BoolNet, BoolSim and Bnet formats);
• the functionalities to export models in different formats used by complementary tools (e.g. the model checker NuSMV or the stochastic simulation tool MaBoSS), including sbml-qual.

Model simulation

GINsim includes a comprehensive panel of functionalities to simulate logical models:

• several simulation tools using different state updating policies (synchronous, asynchronous, sequential, ...);
• simulation settings for model perturbations (constraining components values as well as interactions functionalities);
• construction of the dynamics in terms of State Transition Graphs (STG) or compacted form of the STGs (Strongly Connected Components graph (SCC) and Hierarchical Transition Graph (HTG));
• estimation of attractors reachability;
• n algorithm to compute the trap spaces of a model, which encompass stable states and subspace approximations of cyclic attractors.

Functionalities for the different graphs

GINsim offers various operations on graphs (LRG, STG, SCC or HTG):

• export in graphical formats (PNG, SVG);
• various graph layout and graph exploration algorithms;
• construction of the SCC graph for LRG and STG;
• saving in different formats.

Interoperability and CoLoMoTo

GINsim can load and export models from the SBML qual format, easing their sharing with other software tools. Its integration in the CoLoMoTo notebook enables the definition of complex, reproducible analysis workflows, for example:

• Efficient reachability analysis using pint;
• Complex reachability analysis using the NuSMV model checker;
• Quantification of reachability probabilities using MaBoSS;
• 2D modelling of a cellular tissue using Epilog.
